Komatsu PC210 User Manual

2-64
PC210/240-ENG
12.7 SWINGING
WARNING
When operating the swing, check that the area around the ma-
chine is safe.
1. Before operating the swing, turn swing lock switch a OFF (CAN-
CELLED).
NOTICE
Check that swing lock lamp b goes out at the same time.
2. Operate the left work equipment control lever c to swing the upper
structure.
3. When not operating the swing, turn the swing lock switch a ON
(ACTUATED).
12. OPERATION
b
a
c

Komatsu PC210 Specifications

General

Bucket Capacity	0.8 - 1.2 m³
Travel Speed	5.5 km/h
Max Digging Depth	6, 620 mm
Max Reach	9, 850 mm
Fuel Tank Capacity	400 l
Engine Model	Komatsu SAA6D107E-1
