Komatsu PC210 User Manual

2-26
PC210/240-ENG
11.6 FRONT WINDOW
WARNING
When opening the front window, always hold grip firmly with
both hands and pull up. If you use only one hand, your hand may
slip and get caught.
It is possible to store (pull up) the front window (top) in the roof of the
operator’s compartment.
When opening
WARNING
When the front window is open, there is danger that it will fall, so
always lock it with left and right lock pins A.
1. Place the work equipment on flat ground and stop the engine.
2. Securely lock the safety lock lever.
3. Confirm that the wiper is stored inside the right frame.
4. Pull lock pins A at the top left and right sides of the front window to
the inside to release the lock.
11. EXPLANATION OF COMPONENTS

Komatsu PC210 Specifications

General

Bucket Capacity	0.8 - 1.2 m³
Travel Speed	5.5 km/h
Max Digging Depth	6, 620 mm
Max Reach	9, 850 mm
Fuel Tank Capacity	400 l
Engine Model	Komatsu SAA6D107E-1
