Komatsu PC210 User Manual

3-53
PC210/240-ENG
24.5.3 LUBRICATE SWING CIRCLE (2 points)
1. Lower the work equipment to the ground.
2. Using a grease pump, pump in grease through the grease fittings
shown by arrows.
3. After greasing, wipe off all the old grease that was pushed out.
24. SERVICE PROCEDURE

Komatsu PC210 Specifications

General

Bucket Capacity	0.8 - 1.2 m³
Travel Speed	5.5 km/h
Max Digging Depth	6, 620 mm
Max Reach	9, 850 mm
Fuel Tank Capacity	400 l
Engine Model	Komatsu SAA6D107E-1
