8
Standard Accessories
Lens Cap CS-A31
Attach it to the objective lens to protect them when
not using this instrument.
USB Cable (2 m) CS-A32
Used for communication between the instrument
and a PC.
AC Adapter AC-A312G (ATS036T-A120)
Supplies power from the AC outlet.
Input: 100 V - 240 V~ 50/60 Hz 1 A Max
Output: 12 V 3 A
Plug design Center-negative
Screw for focus ring lock CS-A38
Locks the focus adjustment ring so that it does not
move unintentionally.
Do not use any screw other than the provided one.
Should it get lost or damaged, purchase a new CS-A38 screw.
When shipped from the factory, this screw holds the focus adjustment ring in place. To move the focus
adjustment ring, loosen this screw.
When storing the CS-3000HDR/CS-3000/CS-2000Plus in the Storage Case (optional accessory), remove
this screw or position it so that it does not hit the packing material.
When inserting the CS-3000HDR/CS-3000/CS-2000Plus in the packaging for transportation, remove this
screw or position it so that it does not hit the packing material.
Calibration Certificate
Software for Spectroradiometers
CS-S30
This software allows the instrument to be controlled
and perform versatile data management from a PC.
Software can be downloaded from https://www.
konicaminolta.com/instruments/download/software/
display/index.html
.
Standard and optional accessories are available with the instrument.
Memo
The shapes of some products may be different from those shown.
