Konica Minolta CS-3000HDR User Manual

102
Explanation
Model CS-3000HDR SPECTRORADIOMETER
Measurement
wavelength range
380 to 780 nm
Wavelength resolution 0.9 nm/pixel
Display wavelength interval 1.0 nm
Wavelength precision ±0.3 nm (center-of-gravity wavelength mercury cadmium lamp: 435.8 nm, 546.1 nm, 643.8 nm)
Spectrum wavelength width 5 nm max. (half width value)
Measurement angle
(electrically switchable)
1° 0.2° 0.1°
Luminance range with
guaranteed accuracy
(Light source A)
0.0001 to 100,000 cd/m
2
0.0025 to 2,500,000 cd/m
2
0.01 to 10,000,000 cd/m
2
Minimum
measurement diameter
ø5 mm (ø1 mm when using
closeup lens)
ø1 mm (ø0.2 mm when using
closeup lens)
ø0.5 mm (ø0.1 mm when using
closeup lens)
Minimum objective distance 350 mm (55 mm when using closeup lens)
Minimum luminance display 0.00002 cd/m
2
Minimum spectral
radiance display
1.0 × 10
–9
W/(sr·m
2
·nm)
Luminance: Accuracy
*1
(Light source A)
± 5 % (0.0001 to 0.0004 cd/m
2
)
± 2 % (0.0004 to 10,000,000 cd/m
2
)
Luminance:
Repeatability
(2σ)
*2
(Light source A)
5% (0.0001 to 0.004 cd/m
2
)
1.5% (0.0004 to 0.001 cd/m
2
)
0.7% (0.001 to 0.003 cd/m
2
)
0.25% (0.003 to 0.05 cd/m
2
)
0.15% (0.05 to 100,000 cd/m
2
)
5% (0.0025 to 0.01 cd/m
2
)
1.5% (0.01 to 0.025 cd/m
2
)
0.7% (0.025 to 0.075 cd/m
2
)
0.25% (0.075 to 1.25 cd/m
2
)
0.15% (1.25 to 2,500,000 cd/m
2
)
5% (0.01 to 0.04 cd/m
2
)
1.5% (0.04 to 0.1 cd/m
2
)
0.7% (0.1 to 0.3 cd/m
2
)
0.25% (0.3 to 5 cd/m
2
)
0.15% (5 to 10,000,000 cd/m
2
)
Chromaticity:
Accuracy
*1
(Light source A)
x: ±0.002, y: ±0.002 (0.001 to 0.05 cd/m
2
)
x: ±0.0015, y: ±0.001 (0.05 to 100,000 cd/m
2
)
x: ±0.002, y: ±0.002 (0.025 to 1.25 cd/m
2
)
x: ±0.0015, y: ±0.001 (1.25 to 2,500,000 cd/m
2
)
x: ±0.002, y: ±0.002 (0.1 to 5 cd/m
2
)
x: ±0.0015, y: ±0.001 (5 to 10,000,000 cd/m
2
)
u’: ±0.0014, v’: ±0.0011 (0.001 to 0.05 cd/m
2
)
u’: ±0.0014, v’: ±0.0006 (0.05 to 100,000 cd/m
2
)
u’: ±0.0022, v’: ±0.0011 (0.025 to 1.25 cd/m
2
)
u’: ±0.0014, v’: ±0.0006 (1.25 to 2,500,000 cd/m
2
)
u’: ±0.0022, v’: ±0.0011 (0.1 to 5 cd/m
2
)
u’: ±0.0014, v’: ±0.0006 (5 to 10,000,000 cd/m
2
)
Chromaticity:
Repeatability
(2σ)
*2
(Light source A)
x: 0.0030, y: 0.0035 (0.001 to 0.003 cd/m
2
)
x: 0.0010, y: 0.0015 (0.003 to 0.1 cd/m
2
)
x: 0.0006, y: 0.0006 (0.1 to 0.2 cd/m
2
)
x: 0.0004, y: 0.0004 (0.2 to 100,000 cd/m
2
)
x: 0.0030, y: 0.0035 (0.025 to 0.075 cd/m
2
)
x: 0.0010, y: 0.0015 (0.075 to 2.5 cd/m
2
)
x: 0.0006, y: 0.0006 (2.5 to 5 cd/m
2
)
x: 0.0004, y: 0.0004 (5 to 2,500,000 cd/m
2
)
x: 0.0030, y: 0.0035 (0.1 to 0.3 cd/m
2
)
x: 0.0010, y: 0.0015 (0.3 to 10 cd/m
2
)
x: 0.0006, y: 0.0006 (10 to 20 cd/m
2
)
x: 0.0004, y: 0.0004 (20 to 10,000,000 cd/m
2
)
u’: 0.0024, v’: 0.0014 (0.001 to 0.003 cd/m
2
)
u’: 0.0009, v’: 0.0006 (0.003 to 0.1 cd/m
2
)
u’: 0.0005, v’: 0.0002 (0.1 to 0.2 cd/m
2
)
u’: 0.0003, v’: 0.0002 (0.2 to 100,000 cd/m
2
)
u’: 0.0024, v’: 0.0014 (0.025 to 0.075 cd/m
2
)
u’: 0.0009, v’: 0.0006 (0.075 to 2.5 cd/m
2
)
u’: 0.0005, v’: 0.0002 (2.5 to 5 cd/m
2
)
u’: 0.0003, v’: 0.0002 (5 to 2,500,000 cd/m
2
)
u’: 0.0024, v’: 0.0014 (0.1 to 0.3 cd/m
2
)
u’: 0.0009, v’: 0.0006 (0.3 to 10 cd/m
2
)
u’: 0.0005, v’: 0.0002 (10 to 20 cd/m
2
)
u’: 0.0003, v’: 0.0002 (20 to 10,000,000 cd/m
2
)
Polarization error 2% or less (400 to 780 nm): 1° and 3% or less (400 to 780 nm): 0.2° and 0.1°
Integration time 0.005 to 92 seconds (NORMAL mode); 0.005 to 16 seconds (FAST mode)
Measurement
time
Standalone
Minimum of 1 second or less (MANUAL mode) to approx. 190 seconds (NORMAL mode)
or maximum of approx. 242 seconds (MANUAL mode)
Communication
*3
Approx. 0.07 seconds (when MANUAL mode, 33.333 ms and INTELLIGENT DARK function are set)
Color space mode L
v
x y, L
v
u’ v’, L
v
T∆uv, XYZ, spectrograph, main wavelength, excitation purity
Color matching
functions
CIE1931 (2°), CIE1964 (10°), CIE170-2:2015 (PA2°, PA10°), any isochromatic function (measurement
software supported)
Optical frequency
detection function
Detectable range: Luminance of 10 to 5,000 cd/m
2
and emission frequency of 10 to 200 Hz.
Detection accuracy: ±0.015 Hz; Detection time: Approx. 3 seconds
Interfaces USB 2.0, RS-232C
Operating
temperature and
humidity range
5 to 30°C, 80% RH max. (no condensation)
Storage temperature
and humidity range
0 to 35°C, 80% RH max. (no condensation)
Power
Dedicated AC adapter (100 to 240 V
, 50/60 Hz)
Power consumption Approx. 20 W
Size 158 (W) × 262 (H) × 392 (D) mm
Weight Approx. 7.0 kg
*1: Average value of 10 measurements in the NORMAL mode, at temperature of 23°C ± 2°C and maximum relative humidity of 65%.
*2: Average value of 10 measurements in the NORMAL mode, at temperature of 23°C ± 2°C and maximum relative humidity of 65%.
*3: When the USB cable is connected. Excluding the time required for display and shutter opening/closing. In an environment
designated by KONICA MINOLTA such as a PC.
Main Specifications
