Konica Minolta CS-3000HDR User Manual

40
Setting
Selecting Measurement Angle
The measurement angle can be selected from 1°, 0.2°, or 0.1°.
For the CS-3000HDR/CS-3000, the measurement angle is switched electrically according to the selec-
tion made on the MENU screen. Motor noise may be heard when switching the measurement angle, but
this is not abnormal.
For the CS-2000Plus, the measurement angle is switched by manually rotating the measurement angle
selector.
For details on measurement distance and diameters, refer to the below table. Attach the closeup lens
(optional accessory) if necessary.
* Factory default setting: 1°
Operating Procedure
1
5, 6
1. Press
MENU
key when the MEAS screen
is displayed.
The MENU screen appears on the LCD.
When the backlight of the LCD has been turned off via
BACKLIGHT
key on the MEAS screen, the
backlight is turned on.
MEAS SNGL
UC00
SPD
N r m
CMF
2 ˚
SYN
[
Hz
]
59.94
ACC
Non
cd
m
2
Lv
x
y
1 ˚
MEAS
MEMORY
OPTION
SETUP
DARK MEASUREMENT
INFORMATION
MENU
2, 3, 4
(Unit: mm)
Minimum
measurement
diameter ø
Maximum
measurement
diameter ø
Minimum
objective
distance
Maximum
objective
distance
Measurement
diameter ø for 500
mm measurement
distance
Measurement
diameter ø for 1,000
mm measurement
distance
(Measurement
angle)
1° 0.2° 0.1° 1° 0.2° 0.1° 1° 0.2° 0.1° 1° 0.2° 0.1° 1° 0.2° 0.1° 1° 0.2° 0.1°
Without
closeup lens
5.00 1.00 0.50 ∞ ∞ ∞ 350 ∞ 7.78 1.56 0.78 16.66 3.33 1.67
With closeup
lens
1.00 0.20 0.10 1.39 0.28 0.14 55.0 70.9 - - - - - -
* The measurement distance is the distance from the tip of the objective lens or the metallic part of the closeup lens.
