82
Communication
This instrument can be used together with a PC for mutual communication. To communicate with a PC,
use the included USB cable (2 m) CS-A32 or an optional RS-232C cable (IF-A37/38).
Memo
Simultaneous use of USB communication and RS communication is not possible.
Connection via USB cable
The USB cable can be plugged/unplugged while power is on, but it is recommended to switch power off
in this case.
Memo
Make sure to attach the RS-232C connector cap. Failure to do so may cause malfunction due to static electricity.
Operating Procedure
1. Slide power switch to OFF (O).
2. Connect the USB cable to the USB connector
of this instrument.
3. Make sure that the USB cable is firmly
connected to the USB connector.
Communication interface in this instrument conforms to USB 2.0.
Hold the USB cable plug when unplugging it. Do not pull the cord.
Plug the USB cable to fit the connector entry point.
To connect this instrument to a PC, install the corresponding USB driver software. The USB driver is
attached to the CS-S30 software for spectroradiometers included in the standard accessories. See the
CS-S30 installation guide for details on installing the USB driver software in a PC.
Connecting to a PC
To Next Page
