KTM 1290 Super Duke R 2017 User Manual

13 SERVICE WORK ON THE CHASSIS 131
13.12 Mounting the helmet lock on the vehicle
Warning
Danger of accidents An attached helmet lock or an attached helmet impair the handling characteristic.
– Do not use the helmet lock to attach a helmet or another object while riding.
– Remove the helmet lock before starting off.
E00692-10
– Remove the passenger seat. ( p. 129)
–
Position steel cable
1
from the tool set with the loop around catch
2
.
Steel cable (60012015000)
– Pass the steel cable through the helmet opening.
–
Position the other loop of the steel cable around catch
3
.
– Carefully position the helmet on the back of the vehicle.
– Mount the passenger seat. ( p. 129)
13.13 Removing the main silencer
R01826-10
–
Remove screw
1
.
– Take off the exhaust clamp.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
