KTM 1290 Super Duke R 2017 User Manual

6 CONTROLS 28
6.5 Light switch
S01714-10
The light switch
1
is fitted on the combination switch on the left.
Possible states
Low beam on – Light switch in position
A
. In this position, the low beam
and the tail light are switched on.
High beam on – Light switch in position
B
. In this position, the high
beam and the tail light are switched on.
Headlight flasher – Light switch in position
C
. The headlight flasher is
operated in this position. The light switch returns automatically to the posi-
tion
A
after use.
6.6 Menu switch
S01715-10
The menu switch is fitted in the middle of the left combination switch.
The menu buttons are used to control the display on the combination instrument.
Button
1
is the UP button.
Button
2
is the DOWN button.
Button
3
is the SET button.
Button
4
is the BACK button.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
