18 ENGINE TUNING 194
Info
When traction control is active, the TC indicator lamp flashes.
When traction control is switched off, the TC indicator lamp is lit.
18.3 Slip adjustment (optional)
402790-01
The slip adjustment is an optional motorcycle traction control function.
The slip adjustment allows the motorcycle traction control to be tuned through nine levels
to the desired characteristic map.
Level 1 allows the maximum slip on the rear wheel, and level 9 the minimum.
The slip adjustment can be set while riding with a closed menu using the UP or DOWN but-
ton.
Info
The slip adjustment is only available in Ride Mode TRACK ( p. 193) (optional).
18.4 Throttle Response (optional)
K00754-01
Possible states
• TRACK – Extremely direct response
• SPORT – Very direct response.
• STREET – Balanced response
The characteristic map of the throttle response can be adjusted in the
Throttle Response menu.
The Throttle Response can also be set while riding with a closed throttle grip and deacti-
vated speed sensor.
Info
Throttle Response is only available with the TRACK drive mode enabled.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
