KTM 1290 Super Duke R 2017 User Manual

6 CONTROLS 30
6.8 Horn button
S01716-11
The horn button
1
is fitted on the combination switch on the left.
Possible states
• Horn button in basic position.
• Horn button pressed – The horn is operated in this position.
6.9 Cruise control system tip switch
M01485-10
The
1
cruise control system tip switch is fitted on the left side of the combination switch.
Possible states
• Cruise control system tip switch in the basic position.
• Cruise control system tip switch pressed to the left. – In this position, the cruise
control system function is switched on and off. The operating mode is displayed in the
combination instrument.
• Briefly press cruise control system tip switch in position RES/+. – The last saved
speed is reapplied. Every subsequent brief pressing increases the target speed by 1
km/h or 1 mph.
• Press and hold cruise control system tip switch in position RES/+. – The target speed
increases in increments of 5 km/h or 5 mph.
• Briefly press cruise control system tip switch in position SET/-. – The cruise control
system function is activated and the current speed is maintained. Every subsequent
brief press reduces the target speed by 1 km/h or 1 mph.
• Press and hold cruise control system tip switch in position SET/-. – The target speed
decreases in increments of 5 km/h or 5 mph.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
