23 TECHNICAL DATA 223

Screw, exhaust clamp on manifold M6 8 Nm (5.9 lbf ft) –

Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, fuel pump M6 6 Nm (4.4 lbf ft) –

Screw, instrument support M6 2 Nm (1.5 lbf ft) –

Screw, license plate holder on lower rear

panel

M6 12 Nm (8.9 lbf ft) –

Screw, radiator hose clip M6 3 Nm (2.2 lbf ft) –

Screw, sensor box M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, shift lever stub M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, shift rod M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, shift shaft deflector on shift

shaft

M6 18 Nm (13.3 lbf ft) Loctite

243™

Screw, side stand stub M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, steering damper, holder, on

frame

M6 8 Nm (5.9 lbf ft) Loctite

243™

Screw, step plate for foot brake lever M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, wheel speed sensor, front M6 4 Nm (3 lbf ft) –

Screw, wheel speed sensor, rear M6 4 Nm (3 lbf ft) –

Nut, exhaust valve throttle cable M6x1 5 Nm (3.7 lbf ft) –

Cable disk nut, exhaust valve M8 7 Nm (5.2 lbf ft) –

Nut, manifold on cylinder head M8 Tightening sequence:

Tighten the nuts evenly. Do

not warp the metal plate.

25 Nm (18.4 lbf ft)

–

Nut, rear sprocket M8 36 Nm (26.6 lbf ft) –

Nut, shift rod M8 12 Nm (8.9 lbf ft) –
