23 TECHNICAL DATA 224

Nut, valve (Super Duke R JP) M8 4 Nm (3 lbf ft) –

Nut, valve (Super Duke R EU/AU) M8 6 Nm (4.4 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, axle clamp M8 15 Nm (11.1 lbf ft) –

Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –

Screw, foot brake lever M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, front brake disc M8 30 Nm (22.1 lbf ft) Loctite

2701™

Screw, front rider footrest bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, ignition lock (tamper-proof

screw)

M8 25 Nm (18.4 lbf ft) –

Screw, rear brake caliper M8 25 Nm (18.4 lbf ft) Loctite

2701™

Screw, rear brake disc M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, shift lever on footrest bracket M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, shift shaft deflector on frame M8 10 Nm (7.4 lbf ft) Loctite

243™

Screw, side stand bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, side stand spring M8 15 Nm (11.1 lbf ft) Loctite

2701™

Screw, steering damper on holder M8 8 Nm (5.9 lbf ft) Loctite

243™

Screw, steering damper on triple clamp M8 8 Nm (5.9 lbf ft) Loctite

243™

Screw, steering stem clamp M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, top triple clamp M8 18 Nm (13.3 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, engine bearer M10 45 Nm (33.2 lbf ft) Loctite

243™
