KTM 1290 Super Duke R 2017 User Manual

6 CONTROLS 34
6.13 Race‑on button
S01717-11
The Race‑on button
1
is fitted on the right side of the combination switch.
Info
The Race‑on button performs the ignition lock function on this vehicle.
The steering can only be locked if the handlebar is turned fully to the left.
Possible states
• Race‑on button in the basic position.
• Race‑on button pressed briefly – Pressing briefly switches the ignition on and
unlocks the handlebar lock or switches the ignition off.
• Race‑on button pressed and held – Pressing and holding switches the ignition off
and locks the handlebar.
6.14 Steering lock
S01723-10
On this vehicle, the ignition/steering lock is replaced by a remote key with transponder
(Race-on key ( p. 35)).
In order to activate the steering lock, the handlebar must be turned fully to the left.
The steering is locked and unlocked electromechanically via the Race-on button
( p. 34).
If the battery voltage of the Race-on key is too low, place either the Race-on key or the
black Race-on key in area
A
and repeat starting.
Info
Store the key safely again as soon as the engine has been started.
Possible states
• Ignition off, steering locked – In this operating mode, the ignition circuit is interrupted
and the steering locked.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
