23 TECHNICAL DATA 220

23.8 Shock absorber

Shock absorber article number 15.18.7Q.22

Shock absorber WP Performance Systems 4618 BAVP DCC

Compression damping, low-speed

Comfort 20 clicks

Standard 15 clicks

Sport 12 clicks

Full payload 12 clicks

Compression damping, high-speed

Comfort 1.5 turns

Standard 1.5 turns

Sport 1.5 turns

Full payload 1 turn

Rebound damping

Comfort 15 clicks

Standard 12 clicks

Sport 10 clicks

Full payload 10 clicks

Spring preload

Comfort 8 mm (0.31 in)

Standard 8 mm (0.31 in)

Sport 8 mm (0.31 in)

Full payload 9 mm (0.35 in)

Spring rate

Default Chapter5
- Table of Contents5
1 Means of Representation10
- Symbols Used10
- Formats Used11
2 Safety Advice12
- Use Definition - Intended Use12
- Misuse12
- Degrees of Risk and Symbols13
- Tampering Warning13
- Safe Operation14
- Protective Clothing15
- Work Rules15
- Environment15
- Owner's Manual16
3 Important Notes17
- Manufacturer and Implied Warranty17
- Operating and Auxiliary Substances17
- Spare Parts, Accessories17
- Service18
- Figures18
- Customer Service18
4 View of Vehicle20
- View of Vehicle, Front Left (Example)20
- View of Vehicle, Rear Right (Example)22
5 Serial Numbers24
- Chassis Number24
- Type Label24
- Key Number25
- Engine Number26
- Fork Part Number26
- Shock Absorber Article Number27
- Steering Damper Article Number27
6 Controls28
- Clutch Lever28
- Hand Brake Lever28
- Throttle Grip29
- Combination Switch, Left Side29
- Light Switch30
- Menu Switch30
- Turn Signal Switch31
- Horn Button32
- Cruise Control System Tip Switch32
- Combination Switch, Right34
- Hazard Warning Flasher Switch35
- Emergency off Switch/Electric Starter Button35
- Race-On Button36
- Steering Lock36
- Immobilizer37
- Race-On Key37
- Opening the Filler Cap38
- Closing the Filler Cap40
- Seat Lock40
- Baggage Lugs41
- Tool Set41
- Opening Storage Compartment42
- Closing Storage Compartment42
- Helmet Lock43
- Supporting Strap43
- Passenger Footrests44
- Shift Lever44
- Foot Brake Lever45
- Side Stand46
7 Combination Instrument47
- Activation and Test47
- Day-Night Mode48
- Warning Notes49
- Indicator Lamps50
- Display52
- Shift Warning Light54
- Fuel Level Display54
- Time55
- Coolant Temperature Indicator55
- Trip Distance Counter56
- Cruise Control Indicator56
- Menu57
- Favorites57
- Set Favorites58
- Trip 158
- Trip 259
- Settings59
- Language60
- Unit Settings60
- Fuel Cons61
- Distance61
- 7.13.10 Temp62
- 7.13.11 Pressure62
- 7.13.12 Service63
- 7.13.13 Clock/Date63
- 7.13.14 Shift Light64
- 7.13.15 Drl64
- Quick Selector 165
- Quick Selector 266
- 7.13.18 Extra Functions67
- 7.13.19 General Info67
- 7.13.20 Warning68
- 7.13.21 Mtc/Abs68
- 7.13.22 Ride Mode69
- Tpms70
- Heated Grips (Optional)71
- Heating (Optional)71
- Quick Shift + (Optional)72
- Track (Optional)72
- Launch Control (Optional)73
- Anti Wheelie Mode (Optional)73
- Bluetooth ® (Optional)74
- KTM MY RIDE (Optional)74
- Pairing (Optional)75
- Audio (Optional)77
- Telephony (Optional)78
8 Ergonomics79
- Handlebar Position79
- Adjusting the Handlebar Position79
- Adjusting the Basic Position of the Clutch Lever81
- Adjusting the Basic Position of the Hand Brake Lever81
- Adjusting the Basic Position of the Foot Brake Lever82
- Setting the Step Plate of the Foot Brake Lever83
- Checking the Basic Position of the Shift Lever83
- Adjusting the Basic Position of the Shift Lever84
- Setting the Shift Lever Stub85
- Adjusting the Tilt of the Combination Instrument86
9 Preparing for Use89
- Advice on First Use89
- Running in the Engine90
- Loading the Vehicle91
10 Riding Instructions93
- Checks and Maintenance Measures When Preparing for Use93
- Starting94
- Launch Control (Optional)96
- Starting off96
- Starting off with Launch Control (Optional)96
- Quickshifter+ (Optional)98
- Shifting, Riding98
- MSR (Optional)103
- Applying the Brakes104
- Stopping, Parking106
- Transport107
- Refueling108
11 Service Schedule111
- Additional Information111
- Required Work111
- Recommended Work113
- Suspension Setting115
- Fork/Shock Absorber115
- Adjusting the Compression Damping of the Fork115
- Adjusting the Rebound Damping of the Fork116
- Compression Damping of the Shock Absorber117
- Adjusting the Low-Speed Compression Damping of the Shock Absorber118
- Adjusting the High-Speed Compression Damping of the Shock Absorber119
- Adjusting the Rebound Damping of the Shock Absorber120
- Measuring the Rear Wheel Dimension Unloaded120
- Checking the Static Sag of the Shock Absorber122
- Adjusting the Spring Pretension of the Shock Absorber122
13 Service Work on the Chassis125
- Lifting the Motorcycle with the Rear Lifting Gear125
- Removing the Rear of Motorcycle from the Lifting Gear125
- Lifting the Motorcycle with the Front Lifting Gear126
- Taking the Motorcycle from the Front Lifting Gear127
- Raising the Motorcycle with the Work Stand (Inserted)127
- Removing the Motorcycle from the Work Stand (Inserted)128
- Cleaning the Dust Boots of the Fork Legs130
- Removing the Passenger Seat131
- Mounting the Passenger Seat131
- Removing the Front Rider's Seat132
- Mounting the Front Rider's Seat132
- Mounting the Helmet Lock on the Vehicle133
- Removing the Main Silencer133
- Installing the Main Silencer135
- Checking the Chain for Dirt136
- Cleaning the Chain136
- Checking the Chain Tension138
- Adjusting the Chain Tension139
- Checking the Chain, Rear Sprocket, Engine Sprocket, and Chain Guide141
- Checking/Correcting the Fluid Level of the Hydraulic Clutch145
14 Brake System147
- Antilock Braking System (ABS)147
- Checking the Brake Discs149
- Checking the Front Brake Fluid Level150
- Adding Front Brake Fluid151
- Checking the Front Brake Linings153
- Checking the Rear Brake Fluid Level154
- Adding Rear Brake Fluid155
- Checking the Brake Linings of the Rear Brake156
15 Wheels, Tires158
- Removing the Front Wheel158
- Installing the Front Wheel159
- Removing the Rear Wheel162
- Installing the Rear Wheel163
- Checking the Tire Condition165
- Checking the Tire Air Pressure167
16 Electrical System169
- Daytime Running Light (DRL)169
- Removing the Battery170
- Installing the Battery172
- Recharging the Battery175
- Changing the Race-On Key Battery179
- Changing the Main Fuse180
- Changing the Fuses in the Fuse Box183
- Checking the Headlight Setting187
- Adjusting the Headlight Range187
- Diagnostics Connector189
- ACC1 and ACC2 Front189
- ACC1 and ACC2 Rear190
17 Cooling System191
- Checking the Coolant Level in the Compensating Tank191
- Correcting the Coolant Level in the Compensating Tank192
18 Engine Tuning195
- Ride Mode195
- Motorcycle Traction Control (MTC)195
- Slip Adjustment (Optional)196
- Throttle Response (Optional)196
19 Service Work on the Engine197
- Checking the Engine Oil Level197
- Changing the Engine Oil and Oil Filter, Cleaning the Oil Screens198
- Adding Engine Oil202
20 Cleaning, Care205
- Cleaning the Motorcycle205
- Checks and Maintenance Steps for Winter Operation207
21 Storage209
- Preparing for Use after Storage210
22 Troubleshooting211
23 Technical Data213
- Engine213
- Engine Tightening Torques214
- Capacities218
- Engine Oil218
- Coolant218
- Fuel218
- Chassis218
- Electrical System220
- Tires220
- Fork221
- Shock Absorber222
- Chassis Tightening Torques223
- Nm (18.4 Lbf Ft)223
- Tightening Sequence225
- Nm (11.1 Lbf Ft)226
- Nm (22.1 Lbf Ft)226
- Nm (13.3 Lbf Ft)226
- Loctite226
- Nm (18.4 Lbf Ft)226
- Nm (5.9 Lbf Ft)226
24 Declarations of Conformity228
- EU Declaration of Conformity228
- FCC Declaration of Conformity228
25 Substances231
26 Auxiliary Substances234
27 Standards236
28 Index of Special Terms237
29 List of Abbreviations238
30 List of Symbols239
- List of Symbols239
- Red Symbols239
- Green and Blue Symbols240
- Index241
