15 WHEELS, TIRES 160

15.3 Removing the rear wheel

Preparatory work

– Lift the motorcycle with the rear lifting gear. ( p. 123)

– Remove the main silencer. ( p. 131)

B04149-10

Main work

–

Remove the inside locking wire

–

Remove the outside locking wire

B04139-10

– Have an assistant operate the rear brake.

–

Loosen nut

and remove it with washer
