KTM 1290 Super Duke R 2017 User Manual

7 COMBINATION INSTRUMENT 53
7.9 Time
E00730-01
The time is displayed in 24 hour format in all languages except for EN-US. The time is dis-
played in 12 hour format if the language is set to EN-US.
The time can be configured in the Clock/Date menu.
Info
The time must be reset after the battery was disconnected or the fuse was removed.
7.10 Coolant temperature indicator
E00729-01
The coolant temperature indicator consists of bars. The more bars that light up, the hotter
the coolant.
Info
When all bars light up, the following warning note ENGINE TEMP HIGH appears .
Possible states
• The engine is cold – Up to three bars light up.
• Engine warm – Four to five bars light up.
• Engine hot – Six to eight bars light up.
• Engine very hot – All eight bars light up red.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
