KTM 1290 Super Duke R 2017 User Manual

7 COMBINATION INSTRUMENT 56
7.13.2 Set Favorites
K00774-01
Condition
• The vehicle is stationary.
– Press the SET button when the menu is closed.
– Press the UP or DOWN button until the Set Favorites menu appears on the display.
– Press SET button.
– Press the UP or DOWN button to select the menu. Press the SET button to set the menu
for quick selection.
The Favorites menu is configured in the Set Favorites menu.
7.13.3 Trip 1
K00750-01
– Press the SET button when the menu is closed.
– Press the UP or DOWN button until the Trip 1 menu appears on the display.
Trip 1 shows the distance since the last reset, such as between two refueling stops. Trip 1 is
running and counts up to 9999.
Ø Speed 1 indicates the average speed based on Trip 1 and Trip Time 1.
Ø Consumption 1 indicates the average fuel consumption based on Trip 1.
Trip Time 1 shows the journey time on the basis of Trip 1 and runs as soon as a speed signal
is received.
Fuel Range indicates the possible distance you can cover with the fuel reserve.
Press and hold the
SET button for 3-5
seconds.
All entries in the Trip 1 menu are reset.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
