77OPERATING THE TRACTOR
BTrailer Electrical Outlet
A trailer electrical outlet is supplied for use with trailer or
implement.
C Function of each terminals in trailer electrical
outlet
(1) Trailer electrical outlet
Terminal Function
(1) Ground
(2)
Tail light
Sidemarker light
Parking light
(3) Turn signal light (LH)
(4) Brake stop light
(5) Turn signal light (RH)
(6) Registration plate light
(7) ---
To Next Page
