Kyocera FS-C8500DN Service Manual

2KA
1-4-23
(2) Self diagnostic codes
Code Contents
Remarks
Causes Check procedures/corrective measures
C0100 Backup memory (EEPROM) device
problem (Main PWB)
Reading from or writing to EEPROM
cannot be performed.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
Device damage of
EEPROM.
Contact the Service Administrative Division.
C0120 MAC address data error
For data in which the MAC address is
invalid.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
C0150 Backup memory (EEPROM) device
problem (Engine PWB)
No response is issued from the device in
reading/writing for 5 ms or more and this
problem is repeated five times succes-
sively.
Mismatch of reading data from two loca-
tions occurs eight times successively.
Mismatch between writing data and
reading data occurs eight times succes-
sively.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
Device damage of
EEPROM.
Contact the Service Administrative Division.
C0160 Backup memory (EEPROM) data
problem (Engine PWB)
Reading data from EEPROM is abnor-
mal.
Data damage of
EEPROM.
Contact the Service Administrative Division.
C0170 Copy counts problem
A checksum error is detected in the main
and sub backup memories for the copy
counters.
Data damage of
EEPROM.
Contact the Service Administrative Division.
Defective PWB. Replace the main PWB or engine PWB and
check for correct operation.
C0180 Machine number mismatch error
Machine number of main PWB and
engine PWB does not match.
Data damage of
EEPROM.
Contact the Service Administrative Division.
C0320 Power CPU communication problem
A communication error is detected 10
times in succession.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
C0640 Hard disk drive problem
The hard disk cannot be accessed.
Poor contact in the
connector termi-
nals.
Check the connection the main PWB and
the hard disk, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective hard
disk.
Run U024 (HDD formatting) without turning
the power off to initialize the hard disk (see
page 1-3-20). Replace the hard disk drive
and check for correct operation if the prob-
lem is still detected after initialization.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
