Kyocera FS-C8500DN Service Manual

2KA
1-4-56
(3) Dirty on the back side.
(4) Image is too light.
Copy example Causes Check procedures/corrective measures
Faulty transfer belt cleaning. Replace the transfer belt unit (see page 1-5-28).
Dirty paper conveying path. Clean the paper conveying path.
Dirty fuser belt or press roller (inner
fuser unit).
Replace the fuser unit (see page 1-5-31).
Copy example Causes Check procedures/corrective measures
Defective
develop-
ing bias
output.
Defective developing
unit.
Run maintenance mode U089 to output four-color bar PG,
check the output status of the four colors, and replace the
developing unit for any faulty color (see page 1-3-35 and
page 1-5-25).
Defective main high volt-
age PWB.
Replace the main high voltage PWB.
Defective high voltage
control PWB.
Replace the high voltage control PWB.
Defective engine PWB. Replace the engine PWB.
Dirty drum. Perform the drum refresh operation (see page 1-3-117).
Defective
transfer
bias out-
put.
Defective transfer high
voltage PWB 1.
Replace the transfer high voltage PWB 1.
Defective transfer belt
unit.
Replace the transfer belt unit (see page 1-5-28).
Defective engine PWB. Replace the engine PWB.
Defective color calibration. Perform color calibration (see page 1-3-113).
Insufficient toner. If the display shows the message requesting toner replenish-
ment, replace the container.
Defective agitation of toner container. Shake the toner container up and down approximately ten
times.
Paper damp. Check the paper storage conditions, replace the paper.

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
