Kyocera FS-C8500DN Service Manual

2KA-2
2-4-1
2-4 Appendixes
Maintenance parts list
Maintenance part name
Part No.
Alternative part
No.
Name used in service manual Name used in parts list
Paper feed pulley PULLEY,PAPER FEED 2AR07220 -
Separation pulley PULLEY,SEPARATION 2AR07230 -
Forwarding pulley PULLEY FEED A 2BJ06010 -
MP paper feed pulley PULLEY,SEPARATION 2AR07230 -
MP separation pulley PULLEY,SEPARATION 2AR07230 -
MP forwarding pulley PULLEY LEADING FEED MPT 302FZ08130 2FZ08130
Registration left roller PARTS,ROLLER REGIST L SP 302FZ94520 2FZ94520
MP paper conveying roller 2 PARTS,ROLLER BYPASS A SP 302FZ94472 2FZ94472
MP paper conveying roller 3 PARTS,ROLLER BYPASS B SP 302FZ94481 2FZ94481
MP middle roller PARTS,ROLLER MID MPT SP 302FZ94490 2FZ94490
MP paper conveying pulley PULLEY MPT BYPASS 302FZ07020 2FZ07020
Middle roller PARTS,ROLLER MIDDLE R SP 302FZ94540 2FZ94540
Upper/Lower feed roller PARTS ROLLER FEED LOW 302H794200 2H794200
Laser scanner unit PARTS LSU UNIT HIGH 302KY93160 2KY93160
Transfer belt unit PARTS TRANSFER BELT UNIT 302KY93151 2KY93151
Transfer roller PARTS ROLLER TRANSFER ASSY SP 302KY94300 2KY94300
Developing unit K PARTS DLP K UNIT 302KY93030 2KY93030
Developing unit C PARTS DLP C UNIT 302KY93040 2KY93040
Developing unit Y PARTS DLP Y UNIT 302KY93050 2KY93050
Developing unit M PARTS DLP M UNIT 302KY93060 2KY93060
Drum unit PARTS DRUM 50 M UNIT 302KY93070 2KY93070
Fuser unit PARTS FUSER UNIT E 302KA93022 2KA93022
PARTS FUSER UNIT A 302KA93011 2KA93011
Eject roller PARTS ROLLER EXIT PR SP 302KA94060 2KA94060
Duplex A roller PARTS,ROLLER DUPLEX A SP 302FZ94620 2FZ94620
Duplex B roller PARTS,ROLLER DUPLEX B SP 302FZ94630 2FZ94630
Rear upper filter FILTER VOC 302H733610 2H733610
Left filter FILTER DUCT PU KME 302H733630 2H733630
Rear lower filter PARTS COVER FILTER UNIT 302H794630 2H794630
Right filter 1 PARTS FILTER VU ASSY 302H794430 2H794430
Front filter FILTER DUST 302H703590 2H703590

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
