13: Maintenance and Diagnostics Settings

EDS1100/2100 Device Server User Guide 108

ICMP Settings

To configure the ICMP network protocol:

1. Select Protocol Stack on the menu bar.

2. Select ICMP.

Figure 13-8 ICMP Protocol

3. Select the appropriate state.

4. Click Submit.

Table 13-9 ICMP Settings

Protocol Stack

ICMP Settings

Description

State The State selection is used to turn on/off processing of ICMP messages.

This includes both incoming and outgoing messages. Choose

Enabled or

Disabled.
