8: Line and Tunnel Settings

EDS1100/2100 Device Server User Guide 53

Figure 8-10 Tunnel 1 Packing Mode (Mode = Timeout)

Figure 8-11 Tunnel 1 Packing Mode (Mode = Send Character)

4. Enter or modify the following settings:

Table 8-12 Tunnel Packing Mode

Tunnel - Packing Mode

Settings

Description

Mode  Select Disable to disable Packing Mode completely.

 Select Timeout to send data after the specified time has elapsed.

 Select Send Character to send the queued data when the send character

is received.
