10: Service Settings
EDS1100/2100 Device Server User Guide 83
2. Enter or modify the following settings:
Table 10-18 RSS
3. Select Submit.
4. In the Current Status table, view and clear stored RSS Feed entries, as necessary.
LPD Settings
The EDS1100/2100 device acts as a print server if a printer gets connected to one of its serial
ports. Selecting the Line Printer Daemon (LPD) link in the Main Menu displays the LPD web page.
The LPD web page has three sub-menus for viewing print queue statistics, changing print queue
configuration, and printing a test page. Because the LPD lines operate independently, you can
specify different configuration settings for each.
LPD Statistics
This read-only page shows various statistics about the LPD server.
To view LPD statistics for a specific LPD line:
1. Select LPD on the menu bar. The LPD web page appears.
2. Select an LPD line at the top of the page.
3. Select Statistics. The LPD Statistics page for the selected LPD line appears.
RSS Settings Description
RSS Feed Select On to enable RSS feeds to an RSS publisher.
Persistent Select On to enable the RSS feed to be written to a file (cfg_log.txt) and to be
available across reboots.
Max Entries Sets the maximum number of log entries. Only the last Max Entries are cached and
viewable.
View Click View to view current data entries.
Note: It may be necessary to remove authentication from RSS access to view data
entries on certain web browsers. Go to HTTP Authentication on page 81 for more
information.
Clear Click Clear to clear data entries.
