10: Service Settings
EDS1100/2100 Device Server User Guide 75
Table 10-7 FTP Settings
3. Click Submit.
TFTP Settings
In the TFTP web page, you can configure the server and view the statistics about the Trivial File
Transfer Protocol (TFTP) server.
To configure TFTP:
1. Select TFTP on the menu bar. The TFTP page opens to display the current configuration.
Figure 10-8 TFTP Configuration
2. Enter or modify the following settings:
Table 10-9 TFTP Server
FTP Settings Description
State Select Enabled to enable the FTP server.
Admin Username Enter the username to use when logging in via FTP.
Admin Password Enter the password to use when logging in via FTP.
TFTP Settings Description
State Select Enabled to enable the TFTP server.
Allow File Creation Select whether to allow the creation of new files stored on the TFTP server.
