Lantronix MatchPort User Manual

14: Advanced Settings
EDS1100/2100 Device Server User Guide 133
XML: Import Configuration
Here you can import a system configuration from an XML file.
The XML data can be imported from a file on the file system or uploaded using HTTP. The groups
to import can be specified by toggling the respective group item or entering a filter string. When
toggling a group item, all instances of that group will be imported. The filter string can be used to
import specific instances of a group. The text format of this string is: <g>:<i>;<g>:<i>;...
Each group name <g> is followed by a colon and the instance value <i>. Each <g> :<i> value
is separated with a semicolon. If a group has no instance, specify the group name <g> only.
To import a system configuration:
1. Select XML on the menu bar and then Import Configuration at the top of the page. The XML:
Import Configuration web page appears.
Figure 14-10 XML: Import Configuration
2. Click one of the following radio buttons:
 Configuration from External file. See Import Configuration from External File on page 133.
 Configuration from Filesystem. See Import Configuration from the Filesystem on
page 134.
 Line(s) from single line Settings on the Filesystem. See Import Line(s) from Single Line
Settings on the Filesystem on page 136.
Import Configuration from External File
This selection shows a field for entering the path and file name of the entire external XCR file you
want to import. You can also browse to select the XCR file.
Figure 14-11 XML: Import Configuration from External File
