EDS1100/2100 Device Server User Guide 27
4: Installation of EDS2100
This chapter describes how to install the EDS2100 device server. It contains the following
sections:
Package Contents
User-Supplied Items
Hardware Components
Installing the EDS2100
Package Contents
The EDS2100 package includes the following items:
One EDS2100 device
One DB9F-to-DB9F serial null modem cable
Power Cube, 100-240 VAC with international adapters
Power cord restraint
Printed Quick Start Guide
User-Supplied Items
To complete your installation, you need the following items:
RS-232/422/485 serial devices that require network connectivity.
A serial cable, as listed below, for each serial device. One end of the cable must have a
female DB9 connector for the serial port.
- A null modem cable, such as the one supplied in your EDS2100 package, to connect the
serial port to another DTE device.
- A straight-through modem cable to connect the serial port to a DCE device.
An available connection to your Ethernet network and an Ethernet cable.
A working power outlet if the unit will be powered from an AC outlet.
