Locatingconnectorsontherearofyourcomputer
Figure2“Rearconnectorlocations”onpage70showsthelocationsoftheconnectorsontherearofyour
computer.Someconnectorsontherearofyourcomputerarecolor-codedtohelpyoudeterminewhereto
connectthecablesonyourcomputer.
Figure2.Rearconnectorlocations
1Powercordconnector
2PS/2mouseconnector
3PS/2keyboardconnector
4DisplayPortconnector
5VGAmonitorconnector6USB3.0connectors(2)
7USB2.0connectors(2)
8Microphoneconnector
9Audioline-outconnector10Audioline-inconnector
11PCIExpressx16graphicscardslot12PCIExpressx1cardslots(2)
13Security-lockslot
14Padlockloop
15Ethernetconnector
16Serialconnector
ConnectorDescription
Audioline-inconnector
Usedtoreceiveaudiosignalsfromanexternalaudiodevice,suchasastereo
system.Whenyouattachanexternalaudiodevice,acableisconnectedbetween
theaudioline-outconnectorofthedeviceandtheaudioline-inconnectorofthe
computer.
Audioline-outconnector
Usedtosendaudiosignalsfromthecomputertoexternaldevices,suchaspowered
stereospeakers(speakerswithbuilt-inamplifiers),headphones,multimedia
keyboards,ortheaudioline-inconnectoronastereosystemorotherexternal
recordingdevice.
70ThinkCentreM73HardwareMaintenanceManual
