Locatingconnectorsontherearofyourcomputer
Figure7“Rearconnectorlocations”onpage77showsthelocationsoftheconnectorsontherearofyour
computer.Someconnectorsontherearofyourcomputerarecolor-codedtohelpyoudeterminewhereto
connectthecablesonyourcomputer.
3
4
5 6
Figure7.Rearconnectorlocations
1Powercordconnector
2PS/2mouseconnector
3PS/2keyboardconnector
4DisplayPortconnector
5VGAmonitorconnector6USB3.0connectors(USBconnectors5and6)
7USB2.0connectors(USBconnectors3and4)
8Microphoneconnector
9Audioline-outconnector10Audioline-inconnector
11PCIExpressx16graphicscardslot12PCIExpressx1cardslots(2)
13Ethernetconnector
14Security-lockslot
15Serialconnector
16Padlockloop
ConnectorDescription
Audioline-inconnector
Usedtoreceiveaudiosignalsfromanexternalaudiodevice,suchasastereo
system.Whenyouattachanexternalaudiodevice,acableisconnectedbetween
theaudioline-outconnectorofthedeviceandtheaudioline-inconnectorofthe
computer.
Audioline-outconnector
Usedtosendaudiosignalsfromthecomputertoexternaldevices,suchaspowered
stereospeakers(speakerswithbuilt-inamplifiers),headphones,multimedia
keyboards,ortheaudioline-inconnectoronastereosystemorotherexternal
recordingdevice.
Chapter8.Locations77
