Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019 111
Implemented CIP™ objects
General CIP objects
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.1 General CIP objects
14.1.1 Identity Object (1 / 0x01)
The "Identity Object" provides the identification and general information about the device.
Class attributes
Instance attributes
Attribute
ID
Service Name Data type Value
1 Get Revision UINT 1 (0x0001)
2 Get Max. Instance UINT 1 (0x0001)
3 Get Number of Instances UINT 1 (0x0001)
6 Get Max. ID Number Class
Attributes
UINT 7 (0x0007)
7 Get Max. ID Number Instance
Attributes
UINT 8 (0x0008)
Attribute
ID
Service Name Data type Value
1 Get Vendor ID UINT 587 (0x024B)
2 Get Device Type UINT 2 (0x0002): AC Drive
3 Get Product Code UINT 8440 (0x20F8)
4 Get Revision: STRUCT of: Firmware revision of the device
Major Revision USINT
Minor Revision USINT
5 Get Status WORD Current device status (status bits)
• Instance attribute "Status" (attribute 5)
( 112)
• EtherNet/IP state diagram
( 44)
6 Get Serial Number UDINT Serial number of the device
7 Get Product Name SHORT_STRING E84DGFCG
8 Get State USINT Current device state:
•0: Nonexistent
•1: Device self-testing
•2: Standby
•3: Operational
• 4: Major recoverable fault
• 5: Major unrecoverable fault
• 6 ... 254: Reserved
• 255: Standard for "Get_Attributes_All"
service
(See also C13861
, LED status displays ( 79))
