Error messages
Mapping of Lenze device errors to DRIVECOM errors
88
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.4 Mapping of Lenze device errors to DRIVECOM errors
Via the instance attribute "FaultCode" of the Control Supervisor Object (41 / 0x29) ( 135) Lenze
device errors are output with the DRIVECOM error numbers.
The following tables show the assignment of the Lenze device errors and "CAN Emergency Error
Codes" to the DRIVECOM errors.
 Reference manual/»Engineer« Online help for the Inverter Drive 8400 motec
Here you will find detailed information about the Lenze error messages listed in the
following table.
Lenze error CAN DRIVECOM error
Error number
[32 bits]
Error message Emergency
Error Code
Error number
[hex]
Error message
xx.0111.00002 Su02: One mains phase is missing 0x3000 0x3000 Voltage
xx.0111.00003 Su03: Too frequent mains switching 0x3000 0x3000 Voltage
xx.0111.00004 Su04: CU insufficiently supplied 0x3000 0x3000 Voltage
xx.0111.00006 Su06: Power input overload 0x3000 0x3000 Voltage
xx.0119.00000 OH4: Heat sink temp. > Switch-off temp. -5°C 0x4000 0x4000 Temperature
xx.0119.00001 OH1: Heatsink overtemperature 0x4000 0x4000 Temperature
xx.0119.00002 OH7: Motor temperature resolver > C121 0x4000 0x4000 Temperature
xx.0119.00003 OH9: Motor overtemperature resolver 0x4000 0x4000 Temperature
xx.0119.00012 Sd6: Error temperature sensor resolver 0x7300 0x7300 Sensor
xx.0119.00015 OH3: Motor temperature (X106) triggered 0x4000 0x4000 Temperature
xx.0119.00020 OH6: Motor temperature MultiEncoder > C121 0x4000 0x4000 Temperature
xx.0119.00021 OH12: Motor overtemperature MultiEncoder 0x4000 0x4000 Temperature
xx.0119.00022 Sd12: Error temperature sensor MultiEncoder 0x7300 0x7300 Sensor
xx.0119.00050 OC5: Ixt overload 0x2000 0x2000 Current
xx.0123.00001 OT1: Maximal torque reached 0x8300 0x8302 Torque limiting
xx.0123.00007 OC7: motor overcurrent 0x2000 0x2000 Current
xx.0123.00014 OU: DC bus overvoltage 0x3100 0x3110 Mains overvoltage
xx.0123.00015 LU: DC bus undervoltage 0x3100 0x3120 Mains undervoltage
xx.0123.00016 OC1: Power section - short circuit 0x2000 0x2130 Short Circuit
xx.0123.00017 OC2: Power section - earth fault 0x2000 0x2120 Short to Earth
xx.0123.00024 Sd2: Wire breakage resolver 0x7300 0x7303 Resolver 1 defective
xx.0123.00026 Sd7: Error encoder communication 0x7300 0x7305 Incremental encoder 1 defective
xx.0123.00027 Sd4: Wire breakage MultiEncoder 0x7300 0x7300 Sensor
xx.0123.00030 OC10: Maximum current reached 0x2000 0x2000 Current
xx.0123.00031 OC17: Clamp sets pulse inhibit 0xF000 0xF000 Additional functions
xx.0123.00032 OS1: Maximum speed limit reached 0x8400 0x8402 Velocity Limiting
xx.0123.00033 OS2: Max. motor speed 0x8400 0x8400 Speed Controller
xx.0123.00056 ID2: Motor data identification error 0xF000 0xF000 Additional functions
xx.0123.00057 ID1: Motor data identification error 0xF000 0xF000 Additional functions
xx.0123.00058 ID3: CINH motor data identification 0xF000 0xF000 Additional functions
xx.0123.00059 ID4: Error resistor identification 0xF000 0xF000 Additional functions
xx.0123.00060 ID7: Motor control does not match motor data 0xF000 0xF000 Additional functions
xx.0123.00062 Sd8: Encoder angular drift monitoring 0x7300 0x7300 Sensor
xx.0123.00065 OC12: I2xt overload - brake resistor 0xF000 0x7110 Brake Chopper
xx.0123.00071 OC11: Current clamp for too long (>1 sec) 0xF000 0xF000 Additional functions
xx.0123.00074 ID5: Error pole position identification 0xF000 0xF000 Additional functions
xx.0123.00075 ID6: Error resolver ident. 0xF000 0xF000 Additional functions
