Technical data
General data and operating conditions
18
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4 Technical data
4.1 General data and operating conditions
 Hardware manual for Inverter Drives 8400 motec
Here you will find the ambient conditions and information on the electromagnetic
compatibility (EMC) that also apply to the Communication Unit.
Range Values
Order designation • E84DGFCGxNx (EtherNet/IP)
• E84DGFCGxJx (EtherNet/IP + Safety)
Communication profile EtherNet/IP
Standards / specifications Safety engineering: EN 954-1, EN 13849-1, IEC 61508
(up to safety category 4)
Interface for communication • EtherNet/IP port 1: M12 socket, 5-pin, D-coded
• EtherNet/IP port 2: M12 socket, 5-pin, D-coded
Network topology Tree, star, and line
Type of node Adapter (slave)
Number of nodes Max. 254 in the subnetwork
Max. cable length 100 m
Vendor ID 587 (0x24B), Lenze (’Lenze AC Tech’ in older Rockwell data)
Device type 2 (0x02), AC Drive
Product code 8440 (0x20F8)
Baud rate • 10 Mbps
• 100 Mbps
Transmission mode Half duplex / full duplex
• If the "Half/Full Duplex" transmission mode is set as default, a crossover
cable must be used.
• Auto-MDIX/auto-crossover only works in the "Auto-negotiation" setting.
Switching method Store-and-forward / cut-through
Switch latency Approx. 125 μs at max. telegram length
External voltage supply • U = 24 V DC (20 V - 0 % ... 29 V + 0 %)
•I
max
= 120 mA
Conformities, approvals • CE
•UR / cUR
(see also hardware manual)
