12 Error messages
This chapter complements the error list in the reference manual and the »Engineer« online help for
the Inverter Drive 8400 motec by EtherNet/IP error messages.
12.1 Short overview of the EtherNet/IP error messages
The following table lists all EtherNet/IP error messages in the numerical order of the error numbers.
Furthermore, the preset error response and - if available - the parameter for setting the error
response are specified.
 Tip!
If you click on the cross-reference in the first column, you will get a detailed description
(causes and remedies) of the corresponding error message.
 Reference manual/»Engineer« Online help for the Inverter Drive 8400 motec
Here you will find general information on diagnostics & fault analysis and on error
messages.
Error no.
[hex]
Subject area
no.
[dec]
Error no.
[dec]
Error text Error type
(Error response)
Adjustable
in
0x01bc3100
444 12544 EtherNet/IP: Exist. connect. to 8400 lost 1: No Response C01501/2
0x01bc5531
444 21809 EtherNet/IP: Memory: No Access 1: No Response C01501/2
0x01bc5532
444 21810 EtherNet/IP: Memory: Read Error 1: No Response C01501/2
0x01bc5533
444 21811 EtherNet/IP: Memory: Write Error
(nt14: COM fault 14)
1: No Response C01501/2
0x01bc6010
444 24592 EtherNet/IP: Restart by watchdog reset 1: No Response C01501/2
0x01bc6011
444 24593 EtherNet/IP: Internal Error 1: No Response C01501/2
0x01bc6100
444 24832 EtherNet/IP: Internal Error 1: No Response C01501/2
0x01bc6101
444 24833 EtherNet/IP: Internal Error 1: No Response C01501/2
0x01bc641f
444 25631 EtherNet/IP: Invalid Parameter Set 1: No Response C01501/2
0x01bc6420
444 25632 EtherNet/IP: Error: Lenze Setting Loaded 1: No Response -
0x01bc6430
444 25648 EtherNet/IP: Invalid Configuration 1: No Response -
0x01bc6533
444 25907 EtherNet/IP: Invalid IP Parameter 1: No Response -
0x01bc8111
444 33041 EtherNet/IP: Fault Mode 1: No Response C13880/2
0x01bc8112 444 33042 EtherNet/IP: Explicit Message Timeout 0: No Response C13880/3
0x01bc8114 444 33044 EtherNet/IP: Overall Ethernet Timeout 0: No Response C13880/4
0x01bc8132 444 33074 EtherNet/IP: Idle Mode
(nt05: COM fault 5)
0: No Response C13880/1
0x01bc8273 444 33395 EtherNet/IP: Duplicate IP Address 1: No Response -
