13 Parameter reference
This chapter complements the parameter list and the table of attributes in the reference manual
and the »Engineer« online help for the Inverter Drive 8400 motec by the parameters of the
communication unit E84DGFCGxxx (EtherNet/IP).
13.1 Parameters of the Communication Unit
This chapter lists the parameters of the E84DGFCGxxx Communication Unit (EtherNet/IP) in
numerically ascending order.
C13000
C13001
 Reference manual/»Engineer« Online help for the Inverter Drive 8400 motec
Here you will find general information on parameters.
Parameter | Name:
C13000 | IP Address
Data type: UNSIGNED_8
Index: 11575 = 0x2D37
Setting of the IP address
Setting the IP configuration of the Inverter Drive 8400 motec
( 31)
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C13000/1 192 IP address (most significant byte)
C13000/2 168 IP address
C13000/3 124 IP address
C13000/4 16 IP address (least significant byte)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13001 | Subnetwork Mask
Data type: UNSIGNED_8
Index: 11574 = 0x2D36
Setting of the subnet mask
Setting the IP configuration of the Inverter Drive 8400 motec
( 31)
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C13001/1 255 Subnet mask (most significant byte)
C13001/2 255 Subnet Mask
C13001/3 255 Subnet Mask
C13001/4 0 Subnet mask (least significant byte)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
