Commissioning
Setting the IP configuration of the Inverter Drive 8400 motec
32
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.3.1 Setting via the EtherNet/IP configurator of the »Engineer«
 How to set the IP parameters via the EtherNet/IP configurator:
1. Execute the menu command Online  PROFINET configurator / EtherNet/IP addresses ....
The "Assign IP addresses" dialog window is opened and all Lenze EtherNet/IP nodes
connected are listed.
 Note!
• Changes in the IP parameters will become effective immediately.
• An existing IP connection to the Inverter Drive 8400 motec will be interrupted.
