Product description
Features and variants
14
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.2 Features and variants
The EtherNet/IP Communication Unit is available in the following versions:
• The EtherNet/IP Communication Unit is ...
• mounted on top of the Wiring Unit (E84DGVNxx);
• supplied internally via the Drive Unit (E84DGDVxxxxxxxx) or externally via a separate
voltage source.
• The I/O connections can be brought into the device via M12 connectors or cable glands.
• Devices without an integrated safety system (safety option) have no analog input and no relay
output.
• The integrated safety system can be used on machines for the protection of persons.
• The Inverter Drive 8400 motec is always an adapter device:
EtherNet/IP adapter with "Level 2" functionality
• 2-port interface with integrated switch functionality
• Access to all Lenze parameters (configurable via TCP/IP using the Lenze »Engineer«)
• Up to 3 TCP/IP socket connections for communication with the Lenze »Engineer«
• Support of "IP Config Pending" (activation of changed IP configuration by "power off/on" or
"type 0 reset")
• Support of the redundancy protocol DLR (Device Level Ring) as "beacon-based ring node"
• Up to 10 input data words to the scanner (20 bytes)
• Up to 8 output data words from the scanner (16 bytes)
• Further CIP features:
• Max. 8 CIP connections
• 1 "exclusive owner" connection
• I/O connection type: cyclic
•Minimum I/O cycle time: 4 ms
• Support of multicast messages, UCMM, ACD, BOOTP/DHCP, VLAN tagging/DSCP
Product series Type designation Product features
Enclosure Connection EtherNet/IP I/O: Connection via terminal I/O: Connection via M12 Safety
Inverter Drives 8400 motec
EtherNet/IP Communication Unit
E84DGFCGFNP IP 65 M12 3× DI
1× DO
2× DI
E84DGFCGENP IP 65 M12 2× DI 3× DI
1× DO
E84DGFCGFJP IP 65 M12 3× DI
1× DO
1× AI
2× DI 
E84DGFCGEJP IP 65 M12 3× DI 2× DI
1× DO
1× AI

