Technical data
Internal switch latency
20
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.4 Internal switch latency
The integrated 2-port switch causes runtime delays. For "store-and-forward" and 100 Mbps, these
runtime delays can be calculated as follows.
Runtime delay for an output data packet of the scanners incl.
32-bit "run/idle header" with 16-bit
sequence counter:
Runtime delay for an output data packet of an adapter without
32/bit "run/idle header":
Example
Delay of an output data packet of the scanners with 8 output data words (16 bytes):
• ((66 permanent bytes + 16 bytes) x 8 x 10 nsec) + 4 μsec
• (82 bytes x 8 x 10 nsec) + 4 μsec
• 6.56 μsec + 4 μsec = 10.56 μsec
Runtime delay = ((66 permanent bytes + I/O data in bytes) x 8 x 10 nsec) + 4 μsec
Runtime delay = ((62 permanent bytes + I/O data in bytes) x 8 x 10 nsec) + 4 μsec
 Note!
The use of external switches can also lead to runtime delays. Depending on the system
constellation, it may be useful to create a star topology or a line/mix topology.
Network topology
( 23)
