Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019 141
Implemented CIP™ objects
Lenze objects
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.4.2 Lenze Class (103 / 0x67)
The "Lenze Class (103 / 0x67)" provides the image of the scanner input data.
The input data for the scanner are placed on the MCI_OUT interface of the Communication Unit and
sent to the scanner via the assembly object instance 111 (0xE6).
Class attributes
Instance attributes
Supported service codes
Attribute
ID
Service Name Data type Value
1 Get Revision UINT 2 (0x0002)
2 Get Max. Instance UINT 1 (0x0001)
Attribute
ID
Service Name Data type Value
1 Get No. of supported Attributes USINT 3 (0x0003)
2 Get Attribute List USINT 1 (0x0001) ... 3 (0x0003)
3 Get I/O image of produced data USINT Image of the scanner input data
Service code
[hex]
Name Description
0x01 Get_Attributes_All Outputs a list of the attributes and the attribute's values for
a certain object.
0x0E Get_Attribute_Single Outputs the value of a certain attribute.
