Lexmark W820 User Manual

27
8 Lift the side guide up slightly and slide it to the left until it lightly touches the side of the print
media. Make sure the guide locks into place in one of the detents at the bottom of the tray.
Note: To install a paper-size label in the paper-size indicator window, refer to the
Setup Guide .
9 Slide the tray all the way into the printer.
Loading trays 4 and 5
Load trays 4 and 5 in the optional high capacity feeder in the same way. See Print media source,
size, and capacity specifications for tray capacities.
Note: Do not load any print media other than paper in trays 4 and 5.
1 Pull the tray toward you.
Paper-size
indicator label
goes in this slot
Paper-size
indicator window
Downloaded From ManualsPrinter.com Manuals
