Technical Information
22
G 1xxx/G 2xxx
3.2 Hard-Wired Electrical Connection
Connect L1 (black) to L on the terminal block, N (white) to N on the terminal
block, and GND to the ground connector.
Note:
Hardwiring the dishwasher should only be done if required by electrical code.
Do not cut the plug off the power supply cord/plug and connect it directly to
the house wiring under any circumstances. This voids the warranty.
For hardwiring, the power cord must be removed from the appliance by
disconnecting the cord from the terminal block located at the lower left front of
the dishwasher, behind the toekick and service panel. Feed the permanent
power supply cable through the strain relief and secure it directly to the
terminal block.
Note:
The appliance must be grounded.
3.3 Plumbing Connections
3.3.1 Intake Connection
The appliance is supplied with a 5-foot-long Double WaterProof System
intake hose, equipped with a ¾-inch female hose connection for connection
to a ¾-inch male hose thread water supply valve.
3.3.2 Drain Connection
The appliance is equipped with a 5-foot-long drain hose for connection to a
¾-inch drain nipple.
