Miele Inspira G 2180 Technical Information

Technical Information
59
G 1xxx/G 2xxx
4 Service
4.1 Removing the Combination Dispenser
1. Remove the door outer panel. See Section 030-4.3.
2. Disconnect all dispenser plug connections.
3. Remove the retaining screws (Figure 020-11, Item 1).
4. Release the retaining clips (2 on top, 1 on bottom) and press out the
dispenser assembly.
5. After replacing the combination dispenser, check it for correct operation
using the service mode.
Figure 020-11: Combination Dispenser Removal
4.2 Cable Holder Removal
1. Remove the door outer panel. See Section 030-4.3.
2. Open the cable holder cover with a screwdriver.
3. Disconnect the ground connection to the door.
4. Loosen the clip.
5. Remove the cable holder.
4.3 Locking Plate Adjustment
Note:
Ensure that the appliance is installed perfectly level.
