Technical Information
71
G 1xxx/G 2xxx
sheeting, which serve as condensation surfaces. The second impeller
transports the water vapor in the appliance to the condensation surfaces.
In Version 2, a split-pole motor (approximately 19 watts) drives one impeller,
which transports cool air to the outer surface of the right side panel.
3 Fault Repair
3.1 Condensation Forms on Adjacent Cabinets
Symptom:
During the drying cycle, condensation may form on the cabinets to the left
and right of the dishwasher.
Cause:
Extraneous air is sucked in the area of the condenser.
Remedy:
1. Remove the right side panel (Section 010-4.1).
2. Seal the opening behind the rib of the condenser with silicone sealer
(such as Thermostat); see Figure 040-2.
Figure 040-2: Condenser Pocket
Note:
In dishwashers starting with production number 33/65009505, the opening
at the condenser pocket is already closed.
Remedy:
Modify the dishwasher with the “Vapors VI” conversion kit.
