5-43
2. Move the snap lock in front of the contact spanner to the unlocking position. Insert a
small flat-bladed screwdriver into the hole on the snap lock and press the snap down
about 1mm. At the same time, push the snap lock forwards with a thumb until the snap
lock and its counterpart separate. Then release the snap lock with a screwdriver.
3. Unscrew the M3×6 screw. Then press down, in turn, the two clips that engage the front
cover. At the same time, pull off the front cover carefully to avoid damaging the cables.
Snap Lock
To Next Page
