Mindray BeneView T8 Service Manual

6-40
P/N Description Qty
M51A-30-80906 MPM-9 module(Nellcor SpO
2
/3/5 lead/without IBP) 1
M51A-30-80907
MPM-10 module main unit (MindraySpO
2
/12
lead/without IBP)
1
115-004912-00 MPM-11 module (Masi SpO
2
/12 lead /without IBP) 1
M51A-30-80913 MPM-12 module (Nell SpO
2
/12 lead/without IBP) 1
115-010731-00 New MPM2 module(Masimo SpO
2
/3/5lead) 1
115-010734-00 New MPM5 module(Masimo SpO
2
/12lead) 1
115-010738-00 New MPM8 module(Masimo SpO
2
/3/5lead/no IBP) 1
115-010740-00 New MPM11 module(Masimo SpO
2
/12lead/no IBP) 1
115-010744-00 New MPM3 module(Nellcor SpO
2
/3/5lead) 1
115-010747-00 New MPM6 module(Nellcor SpO
2
/12lead) 1
115-010750-00 New MPM9 module(Nellcor SpO
2
/3/5lead/no IBP) 1
115-010753-00 New MPM12 module(Nellcor SpO
2
/12 lead) 1
115-010755-00 New MPM1 module(Mindray SpO
2
/3/5lead) 1
115-010758-00 New MPM4 module(Mindray SpO
2
/12lead) 1
115-010761-00 New MPM7 module(Mindray SpO
2
/3/5lead/no IBP) 1
115-010764-00 New MPM10 module(Mindray SpO
2
/12lead/no IBP) 1
6.11.4 Cables
P/N Description Remarks
Main unit
6800-20-50156 Alarm LED board cable /
6800-20-50157 Touchscreen control board cable /
6800-20-50159 Power switch & LED board cable /
6800-20-50298 Cable from power board to battery interface board /
6800-20-50301 Cable from recorder to main board /
6800-20-50304 DVI interface board signal wire
DVI interface board
to CIS assembly
6800-20-50305 power board DC output cable /
009-003228-00 iView flat wire /
009-003229-00 USB cable /
6800-20-50334 17” LCD flat wire (T8) Mother board to LCD
6800-20-50512
15-inch screen, flat cables (only used together
with optional screen 0000-10-11068）(T6)
6800-20-50512
6801-20-50973 15-inch AU screen cables (T6) 6801-20-50973
