6.11 Replaceable Parts
To replace the parts, please refer to 5 Repair and Disassembly and the exploded views above.
NOTE
z Here we list most replaceable parts. If you need more parts, please contact our
Customer Service Department.
6.11.1 Main Unit
P/N Description Qty
Rear housing assembly
6800-20-50194 or
043-004045-00
Recorder cover 1
TR6F-30-67306 or
115-001290-00
TR6F recorder 1
6800-20-50301 Recorder to main board cable 1
6800-20-50197-51 or
044-000447-00
Mains container 1
6800-20-50298 Cable, power board to battery interface board 1
6800-20-50155 Cable, main unit to infrared communication board 1
051-000243-00 6800 3-slot module rack communication board 1
6800-30-50073 MPM module rack communication board 1
6800-30-50075 NiosII module 1
0000-10-11063 CF card 1
6800-20-50198-51 Key pad 1
043-000060-00 or
043-000060-01
Rear housing (new interface) 1
6800-20-50672 Cable, main board to DIV interface board 1
6800-20-50673 Cable, main board to USB interface board 1
6800-30-50532 or
115-003232-00
Main board assembly 1
6800-30-50401 WLAN&CF card flexible cable 1
115-001868-00 6800 CF assembly (9211 driving board) 1
6800-30-50476 or
Interface board assembly 1
