Mindray DC-70 Exp User Manual

8-26 Field Replaceable Unit
G3 115-075420-00 24V to 12V Power Conversion
board(FRU)
1 /
G4 115-074598-00 Battery Connecting Board(FRU) 2 Including one pcs battery connecting board.
G5 115-059038-00 AC-DC Module(2143/FRU) 1 /
G6 043-003480-00 base filter 3 Including one dust-proof filter.
G7 115-058955-00 Li-ion battery 2 Including two pcs batteries. For CEexcept
india
115-081617-00 Li-ion battery 2 Including two pcs batteries only for India
8.2.8 Cable (H0)
No.
Order Number
Part Name
Qty.
Remark
H1 009-009186-00 USB cable for keyboard 1 Control panel,J4 - Small keyboard
H2 009-003647-00 HEATER PWR CABLE 1 Control panel,J6 - Gel warmer port
H3 2108-20-65853 STC connecting cable 1 Control panel,J7 – TGC board,J1
H4 009-003635-00 encoder signal wire 1 Control panel,J2 – Encoder board,J1
H5 009-004599-00 Trackball connecting cable 1 Control panel,J8 - Trackball
H6
009-009185-00
cable for USB CONN
1
Control panel,J12/13 - USB port
H7 009-002560-00 USB CABLE 1 Control panel,J10 - System mother board,J45
H8 009-002671-00 Signal cable of the Printer 1 System mother board J47-printer chamber
