Mindray DC-70 Exp User Manual

11-8 System Diagnosis and Support
11.3 Alarming and Errors
The system is equipped with alarming function. When the machine fails, it pops up the alarming
dialogue box, and simultaneously generates LOG file which is saved in the system log. The LOG
file is saved under D:\DC70\LOG.
11.3.1 Battery Error
11.3.2 Abnormal Voltage of System Power
Description:
The asterisk “***” represents the time in LOG record. The format is: 2011-6-12
14:15:15
Alarming tips LOG record Suggestion
Battery communication is abnormal. The capacity
of the battery cannot appear properly. The current
battery is unusable.
*** Battery I2C
error
Check the battery
connection or replace
the battery.
N/A
*** Battery I2C
error，Shutdown
State
Check the battery
connection or replace
the battery.
Battery error. Discharge/charge does work. *** battery break Replace the battery
Alarming tips LOG record Suggestion
The real-time
battery runs
out, please
replace it.
*** System Monitor: Power supply alert!
[XXX], Current voltage: [VVV] V, Limit
voltage:[LLL]~[HHH]V
Replace button battery
N/A
*** System Monitor: Power supply alert!
[XXX], Current voltage: [VVV] V, Limit
voltage:[LLL]~[HHH]V
[XXX] represents voltage name, [VVV]
represents the current value, and [LLL]-[HHH]
represents the upper and lower limits. The
voltage names respectively are:
Back-end power supply: VDD18, VDD25,
VDD12, VCC, D5V, 12V_ACDC, D3V3
Front-end power supply: A5V7,A6V,A2V1
1. If a certain segment of the
circuit among D5V, 12V_ACDC,
D3V3, A5V7, A6V and A2V1
goes higher or lower, replace
DC-DC board.
2 If a certain segment of the
circuit among VDD18, VDD25,
VDD12 and VCC goes higher or
lower, replace the PC carrier
board.
