13-6 Troubleshooting of Regular Malfunctions
same or varied ports
2
Probe board ID of the system
/
13.4.3 Troubleshooting of Probe Socket System
No.
Fault
Description
Cause Analysis Solution
1 Probe cannot
be recognized
This probe cannot be recognized if connected to all
sockets, while other probes work well. The malfunction
of the probe.
Replace the
probe.
This probe cannot be recognized when connected to a
certain socket. Probe board malfunction.
Replace probe
assembly
Arbitrary probe cannot be recognized on all sockets;
The system cannot read the information from probe
board ID;
Probe board malfunction.
Replace probe
assembly
13.5 IO Interface System Failure
13.5.1 Related Modules or Boards
No.
Description
Remarks
1 PC carrier board /
2 PC module /
3 IO assembly /
13.5.2 Key Points Supporting Troubleshooting
No.
Key Points Supporting Troubleshooting
Remarks
1 Working conditions of each USB interface and the
parts available on USB.
See the distribution of USB
2 Self test for Audio Test /
3 Self test for Microphone Interface Test /
4
Output conditions of video interfaces for S-video
and VGA.
See Figure 6.5.
5
Printing condition of video printer.
Check whether the output of
connected video printer works well.
