Description of Self Test Items C-1
Appendix C Description of Self
Test Items
Description of Self Test Items (New PC Box Assembly after EAF518F)
Z0201 PC Module and MF FPGA Interconnection Test
CPU and GPU Temperature Pressure Test
Z0203 MF FPGA and System Monitor Interconnection Test
Z0204 ADC Pressure Test
Z0205 Back End Voltage Monitor Test
Z0206 System Temperature Test
Z0207 Fan Speed Test
Z0208 Speaker Test
Microphone Interface Test
Z0210 Network Interface Test
Z0211 WIFI Function Test
Z0212 MF FPGA Memory Test
Z0301 Front End Voltage Monitor Test
Z0401 DSP FPGA and TRA Interconnection Test (Control Interface)
Z0402 TRA AFE SPI Interface Test
Z0404 TRA Transmission and Reception Function Test
Z0405 DSP FPGA and TRA Interconnection Test (Data Interface)
Z0501 PC Module and DSP FPGA Interconnection Test
Z0502 DSP FPGA DDRIII Test
Z0503 ATGC Function Test
Z0601 MF FPGA and PHV ARM Interconnection Test
Z0603 PHV Board HV Test
Z0701 DSP FPGA and CPLD Interconnection Test
Z0702 HALL Signal Test
Z0801 Control Panel USB Interconnection Test
Z0802 Control Panel Key, Encoder, TGC, Trackball Function Test
Z0803 Control Panel Key LED Test
Primary LCD Monitor I2C Interconnection Test
